LASER CUTTING : METALS & NON-METALS
Our laser cutting capabilities
To ensure that we can provide laser-cut parts to the highest degree of quality, we provide different laser-cutting technologies, including CO2 and fiber, and each technology is specially matched to different materials to provide consistent results.
Regardless of the material, quantity, or size, all parts have a dimensional accuracy of +/- 0.2mm, a minimum feature size of 1x2mm, and a minimum laser kerf of 0.1mm. The maximum material thickness that our laser cutting stations can handle is 32mm (before the laser kerf becomes too large), the maximum dimension for parts made from any sheet material is 6000mm x 2400mm.
![](https://alclaser.com.au/wp-content/uploads/2023/11/section2-photo2-scaled.webp)
![](https://alclaser.com.au/wp-content/uploads/2023/11/Section2-photo1.webp)
Our CO2 laser cutting capabilities
Min lead time
Same day
Same day
Material thickness
0.1 - 20mm
0.1 - 20mm
Part quantity
1 - 100,000
Max laser power
300W
Max part size
3000mm  × 1500mm
Freight options
Courier delivery / customer
pick-up available
Laser kerf
0 - 0.2mm
Â
Min feature size
1  × 2mm
Our fiber laset cutting capabilities
Min lead time
Same day
Â
Material thickness
0.5 - 32mm
Â
Part quantity
1 - 100,000
Max laser power
8KW & 6KW top of the range machines
Â
Max part size
6000mm × 2400mm
Â
Freight options
Courier delivery / customer
pick-up available
Laser kerf
0 - 0.13mm
Min feature size
1× material thickness (min 2mm)
